Focus on the most basic of PCB, components focused on one side, the other side of the wire is concentrated.Because wires only appear on one side, so this kind of PCB is called single sided PCB.
Single panel wiring diagram is given priority to with the network printing, that is, in the copper surface printed on resistance agent, to prevent welding resistance after etching printed on mark, and then punching processing way to complete the parts guide hole and the appearance.In addition, part of a small amount of diverse products, are using photosensitive resistance agent forming pattern of the photographic method.
Operating temperatures range from 130 C to 230 C. Single sided boards are available with surface finishes including Organic surface protectant (OSP), Immersion Silver, Tin, and Gold plating along with both leaded or lead-free Hot Air Solder Level (HASL).
Single sided PCB base material in paper phenolic copper paper laminated board, epoxy resin copper laminated plate is given priority to.
First, the copper foil to be etched, etc. Process to obtain a circuit required, a protective film to be drilled to expose the corresponding pad. After cleaning and then rolling method to combine the two. Then the pad portion exposed gold plating or tin protection.
Single copper-clad plate - blanking - photochemical method/screen printing image transfer - remove corrosion was printed - cleaning, dry - hole machining - shape - dry cleaning - printing resistance welding coating - cure - printing mark symbol - cure - dry cleaning drying - pre coated flux - a finished product
Single sided PCB most use in the radio, heating machine, cold storage, washing machines and other electrical appliances product, as well as the printer, vending machines, LED lighting, electronic components, such as commercial machine circuit
single sided pcb,
printed circuit board
Single sided PCB, printed circuit board with FR4 CEM1 and 22F material
The sing side PCB have wiring only one side of insulating substrate, the side containing the circuit pattern is called the solder side, while the other side is called the component side, this king of pinted circuit board is most common used in case of simple circuitry
Single side PCB is typically made using the print and etch method, components are using to jump over conductor tracks, if it is not possible, jumper wires can be used. The number of jumper wires on a board is limited. Which results in the requirement for double side circuit boards
The single side PCB, which is available at low price from China, applications to radio, heaters, refrigerators, washing machines,printers, vending machines, electronic components and other commercially produced devices.
