Testing Procedures For PCB Board
---We perform multiple quality assuring procedures before shipping out any PCB board. These include:
* Visual Inspection
* Flying probe
* Bed of nails
·* Impedance control
·* Solder-ability detection
* Digital metallograghic microscope
·*AOI (Automated Optical Inspection)
Detailed Terms for PCB Manufacturing
---Technical requirement for pcb assembly:
* Professional Surface-mounting and Through-hole soldering Technology
* Various sizes like 1206,0805,0603 components SMT technology
* ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
* PCB Assembly With UL,CE,FCC,Rohs Approval
* Nitrogen gas reflow soldering technology for SMT.
* High Standard SMT&Solder Assembly Line
* High density interconnected board placement technology capacity.
Surface Treatment
Lead-free HAL
Gold Plating (1-30 micro inch)
OSP
Silver Plating
Pure Tin Plating
Immersion Tin
Immersion Gold
Gold Finger
Other Service:
A) We have many special material as rogers, teflon, taconic, Fr-4 high tg, Ceramic in stock. Welcome to send us your inquiry.
B) We also provide sourcing components , PCB design , PCB copy , PCB drawing , PCB assembly and so on .
Product Details:
Payment & Shipping Terms:
|
High Light: | Custom Printed Circuit Board,Custom PCB Design |
---|
Silver Custom PCB Boards with 0.05mm Hole Tolerance for UV LED PCB Board Design
PCB Name: | Silver Custom PCB Boards | Layer count | 2 Layer |
Base Material: | FR4 | Board Thickness: | 1.6mm |
Copper Thickness: | 1oz | Min. Hole Size: | 0.4mm |
Min. Line Width/Spacing: | 0.2mm/0.2mm | Surface treatment: | Immersion Silver |
Solder mask color: | Red | Silkscreen color: | White |
Description:
Applications:
Point to Point Microwave Transceivers, UV LED Light, EgoTwist,Police/ Fire/ Rescue Radios, Digital Network Equipment, SatCom transceivers, Wearable electronics,Commercial and Private Aircraft Radios and Instrumentation, Home Appliances ,Air Conditioners, Coffee Makers, Electric Heaters, Fans Electric, Irons Refrigerators, Solar Water Heaters, Vacuum Cleaners Washing Machines, Electric Ovens, Coffee Makers, Blenders Induction Cookers Microwave Ovens Rice Cookers, Dish Washers, splitters and combiners, high power transistors,Weather Radar and Weather related Telemetry, Oscilloscopes, Network Analyzers, Ohm Meters ect.
Specifications:
Layer count | Single sided, Double sided, Multilayer to 26 Layers |
Base material | FR4, High Tg FR4, Aluminum Metal core |
Board thickness | 0.2mm-4.0mm |
Maximum Board Size | 580mmx700mm |
Copper thickness | 0.5oz-6oz |
Minimum Hole Size | 0.2mm |
Minimum Trace/Space | 4mil/4mil |
Surface finish | HASL,Pb Free HASL,ENIG,Plating Gold Silver Immersion, OSP |
Solder Mask | Green, Red, Blue, Black, Matte Green, Orange |
Silk Screen | White, Yellow, Black |
PCB Fabrication | Scoring, Route, V-Score, Counter Sink, Bevel, Cutouts,Slots |
Quality Control | IPC 6012 Class 2, Electrical Test, Flying probe Test |
Special Technology | Alu metal core, Heavy copper weight, Half Plated Thru Hole, Impendence Control PCB, Blue mask PCB |
Advantage:
Contact Person: Miss. aaa
Tel: 86 755 8546321
Fax: 86-10-66557788-2345
