Single Sided PCB

  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers

Introduction:

Focus on the most basic of PCB, components focused on one side, the other side of the wire is concentrated.Because wires only appear on one side, so this kind of PCB is called single sided PCB.

Single panel wiring diagram is given priority to with the network printing, that is, in the copper surface printed on resistance agent, to prevent welding resistance after etching printed on mark, and then punching processing way to complete the parts guide hole and the appearance.In addition, part of a small amount of diverse products, are using photosensitive resistance agent forming pattern of the photographic method.

Operating temperatures range from 130 C to 230 C.  Single sided boards are available with surface finishes including Organic surface protectant (OSP), Immersion Silver, Tin, and Gold plating along with both leaded or lead-free Hot Air Solder Level (HASL).








Material:





Single sided PCB base material in paper phenolic copper paper laminated board, epoxy resin copper laminated plate is given priority to.





Structure:



First, the copper foil to be etched, etc. Process to obtain a circuit required, a protective film to be drilled to expose the corresponding pad. After cleaning and then rolling method to combine the two. Then the pad portion exposed gold plating or tin protection.





Production Process:


Single copper-clad plate - blanking - photochemical method/screen printing image transfer - remove corrosion was printed - cleaning, dry - hole machining - shape - dry cleaning - printing resistance welding coating - cure - printing mark symbol - cure - dry cleaning drying - pre coated flux - a finished product




Application



Single sided PCB most use in the radio, heating machine, cold storage, washing machines and other electrical appliances product, as well as the printer, vending machines, LED lighting, electronic components, such as commercial machine circuit




Blank Single Side PCB Board Immersion Tin , Immersion Silver / FR4 base

Blank Single Side PCB Board Immersion Tin , Immersion Silver / FR4 base
Blank Single Side PCB Board Immersion Tin , Immersion Silver / FR4 base

Large Image :  Blank Single Side PCB Board Immersion Tin , Immersion Silver / FR4 base

Product Details:

Place of Origin: shen zhen ,china
Brand Name: WonDa
Certification: CE, ROHS, UL

Payment & Shipping Terms:

Minimum Order Quantity: None
Price: Negotiable
Packaging Details: Vacuum bag + Outer carton
Delivery Time: 5-15 days
Payment Terms: L/C,T/T,Paypal
Supply Ability: 10000 Sq.meter/month
Detailed Product Description
High Light:

single sided printed circuit boards

,

blank circuit board

Blank Single Side PCB Board Immersion Tin , Immersion Silver / FR4 base



Quick Details



Place of Origin: China (Mainland) Brand Name: OEM Model Number: PCB-08-034
Base Material: FR4 Copper Thickness: 0.25oz~6oz Board Thickness: 0.1mm~6.0mm
Min. Hole Diameter: 0.1mm Min. Line Width: 0.075mm Min. Line Spacing: 0.075mm
Surface Finishing:
Lead Free HASL, ENIG, Immersion Tin, Immersion Silver, OSP et




Specifications

Blank Single Side PCB Board
1.Fast and one-stop service
2.Accept Design,Clone,OEM
3.Small order is accepted.



Wonda PCBA Limited major in Double Side PCB, Multi-Layer PCB, F4BK PCB, Ceramic PCB,  Rogers



PCB, Aluminum PCB.



Technical Parameters



Brand Name:Wonda

Model Number: PCB-08-032

Base Material:ceramic , F4 BK-2 , Aluminum, Rogers, High Tg FR4, FR1, CEM-1, FR4,etc

Layer:1-22 Layers

Board Thickness:0.1~6.0mm

Copper Thickness:0.25~6.0oz

Min.hole size:0.1mm

Min.line width:0.075mm(3mil)

Min.line spacing:0.075mm(3mil)

Surface Finishing: Lead Free HASL, ENIG, Immersion Tin, Immersion Silver, OSP etc.

Customize:yes
