Electric Motor Copper Strip Wire Brass Alloy Strip For Electron Component C27000
quick Detail:
|
Standard Range of Coppers and Copper Alloys Manufactured
|
|
coppers
|
CDA 10200,11000 and 12200 Best Sales Item
|
|
Radiator
|
CDA 14000 series
|
|
Lead frame
|
CDA 19210 new and best
|
|
Plain Brassed
|
CDA 20000 series
|
|
Phosphor Bronzes
|
C51000, C51010, C51110, C52100, and C52400
|
|
Nickel Silvers
|
CDA 73000 to 77000
|
Description:
Specifications of Oxygen Free Copper Strip:
1. Grade: C1100 , C1020
2. Thickness: 0.005mm- 1.2mm
3. Width: 400mm max
4. Chemical Composition: C1100: Cu >99.90%
C1020: Cu >99.96%
C1220: Cu >99.97%; P 0.015-0.04%
5. Oxygen content: C1100: O < 500PPM
C1020: O < 50PPM
6. Temper: O, 1/4H, 1/2H, H
O: HV<70; 1/4H: HV 65-85; 1/2H: HV 80-100; H: HV >100
7. Electric 20°C Conductivity: C1100/C1020 >97%; C1220 >80%
Chemical composition
|
|
Cu
|
O
|
P
|
|
C1100
|
99.90%
|
500PPM
|
-
|
|
C1020
|
99.96%
|
50PPM
|
-
|
|
C1220
|
99.97%
|
-
|
0.015-0.04%
|
|
Item
|
nominal thickness
|
|
Double shiny
|
Single (double) matte
|
Super matte
|
|
8µm
|
9µm
|
12µm
|
15µm
|
20µm
|
10µm
|
12µm
|
10µm
|
12µm
|
|
Area Weight
(g/m2)
|
70~75
|
85~90
|
100~105
|
128~133
|
175~181
|
95~100
|
105~110
|
95~100
|
105~110
|
|
Tensile Strength
(kg/mm2)
|
Normal temperature
|
≥30.0
|
≥30.0
|
≥30.0
|
≥30.0
|
≥30.0
|
≥25.0
|
≥25.0
|
≥25.0
|
≥25.0
|
|
Elongation
(%)
|
Normal temperature
|
≥5.0
|
≥5.0
|
≥5.0
|
≥6.0
|
≥8.0
|
≥2.5
|
≥2.5
|
≥3.0
|
≥3.0
|
|
Roughness Rz(µm)
|
≤3.0
|
negotiable
|
|
Thickness
(µm)
|
(-0;+3)
|
negotiable
|
|
Oxidation resistance
(160°C/10min)
|
No oxidation and discoloration
|
Applications for Oxygen Free Copper strip:
1. Electric and electric springs, switches
2. Lead frames
3. Connectors and oscillation reeds
4. PCB field
5. Communication cable
6. Cable armoring
7. Mobile phone main board
8. Ion battery production lamination with PI film
9. PCB collector (electrode backing) materials
Manufacturing of Copper Strip(Copper Tape):
Features for Oxygen Free Copper Strip :
1) Enjoy good electricity and heat conduction;
2) Elongation;
3) Good corrosion-resistance and climate-hardiness.
Why to choose Zixu Shengye(Kunshan) as your supplier?
1. Since 1992, we have already occupied a lot of market in China.
2. Good reputation in Aluminum and Copper Areas.
3. Good relationship with the Chinese aluminium and copper mills.
4. Abundant economic strength.
5. Good experience and cooperation with big client, like ABB, Zixu Shengye is qualified supplier.
6. With Certificate ISO9001, ISO14001 and OHSAS 18001
7. Big Storage warehouse in Shanghai, clients can get the products at any time(24 hours each day).
8. Zixu has own factory to make further process to cut the coils to be detailed strip and plates as clients’ demand.
9. Good communication skills, and good service and understandings for customers’ needs.
10. Delivery the goods on time.
11. Perfect quality of the goods with all the mill certificate.
12. Strong Sea-worthy package.
