FPC Stainless Steel Sheets PCB Board Material , Ni thickness 2～8um

Name: FPC Stainless Steel Sheets PCB Board Material , Ni thickness 2～8um
Brand: Zhengye
SKU: FPC Stainless Steel Sheets
Rating: 4.9 (196 reviews)

Large Image : FPC Stainless Steel Sheets PCB Board Material , Ni thickness 2～8um

Product Details:

Place of Origin:	China
Brand Name:	Zhengye
Model Number:	FPC Stainless Steel Sheets

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiation
Packaging Details:	Wooden Carton
Delivery Time:	negotiation
Payment Terms:	T/T
Supply Ability:	negotiation

Contact Now

Detailed Product Description

Item:

Production Ability

Steel Distance:

0.4mm

Outer Dimension:

Min：2mm*2mm；Max：100mm*100mm

Surface Treatment:

Ni Thickness 2～8um

Highlight:

pcb board material

flexible pcb material

FPC Stainless Steel Sheets PCB Board Material In Industrial / Electronic

FPC Stainless Steel Sheets

Product Attributes:

Product name	FPC Stainless Steel Sheets
Brand Name:	Zhengye
Model Number:	/
Place of Origin:	China
Packaging Details:	Wooden Carton

FPC Stainless Steel Sheets Use:

Due to the stainless steel material is provided with a series features such as excellent corrosion resistance

and form ability,compatibility,and robustness within a wide temperature range, it is widely used in industrial,

electronic, supplies, and building decoration industry areas.

FPC Stainless Steel Sheets Features:

PASTED TO THE CONNECTING FIGERS TO STIFFEN THE FPC strength in order to facilitate
assembly.General thickness is 0.2mm
Adding a steel plate to the bottom of the main keyboard for positioning and to ensure a nicer touch.
Thickness is about 0.4mm

Parameters:

Production Ability
NO.	Item	Production Ability
1	Hole Diameter	0.05mm～0.01mm hickness≥0.5mm hole diameter
		0.15mm～0.2mm hickness≥0.8mm hole diameter
		0.2mm～0.3mm hickness≥1.0mm hole diameter
		0.4mm～0.5mm hickness≥1.5mm hole diameter
2	Steel Thickness	Max thickness≥0.5mmMin thickness ≤0.5mm
3	Steel Distance	0.4mm
4	Outer Dimension	Min:2mm2mm；Max:100mm100mm
5	Outer Tolerance	Dimension Tolerance +0.03mm～0.05mm, +0.05mm～0.03mm,±0.03mm
6	Surface Treatment	Ni thickness 2～8um

Etching Ability
Ordinal	Item	Production Ability
1	Hole Diameter	Below 0.2mm thickness ≥0.15mm
		Below 0.3mm thickness ≥0.3mm
		Above 0.3mm thickness≥0.5mm
2	Steel Thickness	Max thickness 0.5mm,Min thickness 0.05mm
3	Steel Distance	≥0.4mm
4	Outer Dimension	Max:700500mm；Min:0.30.3mm
5	Hole Diameter Edge to Outer	T ≤0.15mm,min≥0.1mm
		T ≤0.2mm,min≥0.15mm
		T ≤0.25mm～0.3,min≥0.175mm
		T ≤0.3mm,min≥0.3mm
6	Surface Treatment	Ni thickness 2～8um
7	Materials	ADThermosetting pure rubber
8	Diviation Tolerance	Mannual position:0.1mm；model adhesive:0.05mm
9	Whole Length Tolerance	TOLERANCE
		Thicknes linear	T<0.3mm	T=0.3—0.35mm	T=0.4—0.5mm
		0＜L≤20	±0.05mm	±0.1mm	±0.15mm
		20＜L≤60	±0.075mm	±0.125mm	±0.15mm
		60＜L≤120	±0.1mm	±0.15mm	±0.15mm
10	Outer Tolerance	Dimension Tolerance +0.03mm～0.05mm,+0.05mm～0.03mm,±0.03mm
