Single Sided PCB

  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers
  • High Precision Single Sided PCB suppliers

Introduction:

Focus on the most basic of PCB, components focused on one side, the other side of the wire is concentrated.Because wires only appear on one side, so this kind of PCB is called single sided PCB.

Single panel wiring diagram is given priority to with the network printing, that is, in the copper surface printed on resistance agent, to prevent welding resistance after etching printed on mark, and then punching processing way to complete the parts guide hole and the appearance.In addition, part of a small amount of diverse products, are using photosensitive resistance agent forming pattern of the photographic method.

Operating temperatures range from 130 C to 230 C.  Single sided boards are available with surface finishes including Organic surface protectant (OSP), Immersion Silver, Tin, and Gold plating along with both leaded or lead-free Hot Air Solder Level (HASL).








Material:





Single sided PCB base material in paper phenolic copper paper laminated board, epoxy resin copper laminated plate is given priority to.





Structure:



First, the copper foil to be etched, etc. Process to obtain a circuit required, a protective film to be drilled to expose the corresponding pad. After cleaning and then rolling method to combine the two. Then the pad portion exposed gold plating or tin protection.





Production Process:


Single copper-clad plate - blanking - photochemical method/screen printing image transfer - remove corrosion was printed - cleaning, dry - hole machining - shape - dry cleaning - printing resistance welding coating - cure - printing mark symbol - cure - dry cleaning drying - pre coated flux - a finished product




Application



Single sided PCB most use in the radio, heating machine, cold storage, washing machines and other electrical appliances product, as well as the printer, vending machines, LED lighting, electronic components, such as commercial machine circuit




One Layer Rigid Custom Printed Circuit Boards, Single Sided PCB Board

One Layer Rigid Custom Printed Circuit Boards, Single Sided PCB Board
One Layer Rigid Custom Printed Circuit Boards, Single Sided PCB Board

Large Image :  One Layer Rigid Custom Printed Circuit Boards, Single Sided PCB Board

Product Details:

Place of Origin: shen zhen ,china
Brand Name: WonDa
Certification: ISO 9001:2008,ISO 14001:2004, UL, SGS, CTI
Model Number: One layer pcb board
Port: Shenzhen / HK

Payment & Shipping Terms:

Payment Terms: L/C,T/T,Paypal
Detailed Product Description
High Light:

single sided board

,

single sided printed circuit boards

One Layer Rigid Custom Printed Circuit Boards, Single Sided PCB Board



Description:

Place of Origin

Guangdong, China (Mainland)

Brand Name

One layer pcb board

Model Number

One layer pcb board

Number of Layers

One layer pcb board

Base Material

CEM-3 FR-4

Copper Thickness

1/2 oz min 4 oz max

Board Thickness

0.2mm-3.20m(8mil-126mil)

Min. Hole Size

0.20mm(10mil)

Min. Line Width

0.075mm(3mil)

Min. Line Spacing

0.075mm(3mil)

Surface Finishing

HASL, HAL Pb Free, HAL, Immersion Gold, Gold Plating, Immersion Tin

Brand



Color

Green, red, white, blue, yellow

Certifications

ISO 9001:2008,ISO 14001:2004, UL, SGS, CTI



Feature:


1. Our PCBs are used for wide range of electronic products
Like Medical devices, CCTV, Power supply, GPS, UPS, Set-top Box,Telecomunication ,LED, etc.
2. Provides OEM services to all sorts of printed circuit board assembly as well as Electronic encased products
3. Solder mask color: Green / Yellow / Black / White / Red / Blue.
4. Board material type: FR-4, Aluminium-backed board, Halogen-free, Lead-free compatible, High-Tg, High CTI, CEM-1, CEM-3, Rogers and more
5. Compound material lamination: 2 to 12 layers
6.Surface Finished type: HASL, Flash golds, ENIG,OSP(lead freecompatible), Carbon ink, Peelable S/M, HASL(lead free), Immersion silver/tin, Gold finger plating, ENIG+gold finger plating, Immersion Silver+gold finger plating
