Material Type:
FR4,non-halogen material ,Aluminum Base, Cooper Base,high frequency material ,Thick copper foil,94-V0(HB),PI Material,HIGH TG:SL S1000-2,ITEQ:IT180
Surface treatment: HAL,Immersion Gold,Immersion Tin,Immersion silver,Gold Finger,OSP,HAL(Immersion Gold,OSP,Immersion silver,Immersion Tin)+Gold Finger
Application
PCBs are applied to a wide range of High-tech industries such as: LED, telecommunication, computer application, lighting, game machine, industrial control, power, automobile and high-end consumer electronics, ect. By unremitting work and effort to the marketing, products exports to American, Canada, Europe counties, Africa and other Asia-pacific countries.
FAQ
What are the available holes sizes?
14 mils to 150 mils - 1 mil increments
150 mils to 200 mils - 5 mil increments
above 200 mils - holes would be routed out
We only use drills in imperial units. Files submitted in metric units (mm) would be converted to imperial units (mils) and rounded up to the next mil.
I am used to designing in metric units while the website is specified in imperial units. Is there a conversion chart I can refer to ?
When requesting an online quote, the quote form can handle mm units as well as inches for dimensions.
How do I specify internal cutouts/milling in my design?
All internal cutouts/slots/milling should be specified on the same layer is the board outline. The the minimum routable slot size is 32 mils. During order time, please state this requirement in the "Special Request" section so that our CAM engineers is aware of it. This is not something we encounter often - so there are chances we may overlook it. Make sure it's known to us.
Product Details:
Payment & Shipping Terms:
|
Base Material: | FR4 | Copper Thickness: | 1oz |
---|---|---|---|
Board Thickness: | 1.6mm | Min. Hole Size: | 0.2mm |
Min. Line Width: | 3mil | Min. Line Spacing: | 3mil |
Surface Finishing: | Spray Tin | Color: | Blue |
Number Of Layers: | 4-Layer | ||
High Light: | pcb prototype board,pcb prototype assembly |
China Printed Circuit Board(PCB) Manufacturer
We are the professional PCB (1-28 layers), FPC (1-10 layers) and Rigid-Flex (1-12 layers) manufacturer.
Description
1. Professional manufacturer of PCB and PCB assembly, specialized in single-sided PCB, double-sided PCB, multilayer PCB, PCB layout and design and PCB assembly.
2. Material Type: FR4, CEM-1, non-halogen material, Aluminium Base, Cooper Base, high frequency material ,Thick copper foil, 94-V0(HB), PI Material, High TG:SL S1000-2,ITEQ:IT180.
3. Surface treatment: HASL, HAL LF, Immersion Gold, Immersion Tin, Immersion silver, Gold Finger, OSP.
Application
Products are applied to a wide range of High-tech industries such as: LED, telecommunication,
computer application,lighting, game machine, industrial control, power, automobile and high-end
consumer electronics, ect. By unremitting
work and effort to the marketing, products exports to American, Canada, Europe counties, Africa and other
Asia-pacific countries
Advantage
1. PCB from factory directly
2. PCB which have the comprehensive quality control system
3. PCB with good price
4. PCB with quick turn delivery time from 48hours.
5. PCB with certification (ISO/UL/RoHS/SGS)
6. PCB with 10 years experience in exporting service
7. PCB is no MOQ/MOV.
8. PCB with high quality. strict test through AOI (Automated Optical Inspection),QA/QC, Flying Proble Test, E-test fixture.
PCB |
High precision prototype |
PCB bulk production |
|
Max Layers |
1-28 layers |
1-14 layers |
|
MIN Line width(mil) |
3mil |
4mil |
|
MIN Line space(mil) |
3mil |
4mil |
|
Min via (mechanical drilling) |
Board thickness≤1.2mm |
0.15mm |
0.2mm |
Board thickness≤2.5mm |
0.2mm |
0.3mm |
|
Board thickness>2.5mm |
Aspect Ration≤13:1 |
Aspect Ration≤13:1 |
|
Aspect Ration |
Aspect Ration≤13:1 |
Aspect Ration≤13:1 |
|
Board thickness |
MAX |
8mm |
7mm |
MIN |
2 layers:0.2mm; 4 layers:0.35mm; 6 layers:0.55mm; 8 layers:0.7mm; 10 layers:0.9mm |
2 layers:0.2mm; 4 layers:0.4mm; 6 layers:0.6mm; 8layers:0.8mm |
|
MAX Board size |
610*1200mm |
610*1200mm |
|
Max copper thickness |
0.5-6oz |
0.5-6oz |
|
Immersion Gold/ Gold Plated Thickness |
Immersion Gold:Au,1—8u” |
||
Hole copper thick |
25um 1mil |
25um 1mil |
|
Tolerance |
Board thickness |
Board thickness≤1.0mm:+/-0.1mm |
Board thickness≤1.0mm:
+/-0.1mm
≤2.0mm:+/-10% |
Outline Tolerance |
≤100mm:+/-0.1mm |
≤100mm:+/-0.13mm |
|
Impedance |
±10% |
±10% |
|
MIN Solder mask bridge |
0.08mm |
0.10mm |
|
Plugging Vias capability |
0.25mm--0.60mm |
0.70mm--1.00mm |
Contact Person: Miss. aaa
Tel: 86 755 8546321
Fax: 86-10-66557788-2345
