Material
FR4,non-halogen material ,Aluminium Base,Cooper Base,high frequency material ,Thick copper foil,94-V0(HB),PI Material,HIGH TG:SL S1000-2,ITEQ:IT180
Surface Treatment
HAL,Immersion Gold,Immersion Tin,Immersion silver,Gold Finger,OSP,HAL(Immersion Gold,OSP,Immersion silver,Immersion Tin)+Gold Finger
Advantage
1.PCB factory directly
2.PCB high quality
3.PCB good price
4.PCB quick time
5.PCB certification(ISO/UL E354810/RoHS)
Capability:
-High Frequency (TACONIC material)/TG/Density/precision impedance controlled boards
-Heavy Copper PCB, Metal based PCB. Hard Gold PCB, Blind &Buried vias boards,
Halogen Free PCB, Aluminum-backed Boards
-Gold finger+ HAL & Leadfree HASL PCB, Leadfree compatible PCB
Product Details:
Payment & Shipping Terms:
|
| Number Of Layers: | 4-Layer | Base Material: | FR4 |
|---|---|---|---|
| Copper Thickness: | 1OZ | Board Thickness: | 2.0mm |
| Min. Hole Size: | 0.3mm | Min. Line Width: | 0.2mm |
| Min. Line Spacing: | 0.2mm | Surface Finishing: | Immersion Gold |
| Impedance Pcb: | High TG Pcb Fabrication | ||
| High Light: | custom circuit board,hdi circuit boards |
||
WonDa, your single point of contact for all of your raw materials, parts, and pcb assembly, also offers:
- Engineering Services
- PCB Design & Assembly
- Product Design
- Prototyping
- Cable and Wire Assemblies
- Plastics and Molds
Detailed Specification of PCB Manufacturing
|
1 |
Layer |
1-28 layer |
|
2 |
Material |
FR-4,CEM-1,CEM-3,Hight TG,FR4 Halogen Free,Aluminum, Ceramic, Rogers,F4B,Teflon |
|
3 |
Board thickness |
0.2mm-6.0mm |
|
4 |
Max.finished board side |
550mm*1100mm(single-sided) 550mm*640mm(multilayer) |
|
5 |
Min.drilled hole size |
0.15mm |
|
6 |
Min.line width |
0.076mm(3mil) |
|
7 |
Min.line spaceing |
0.076mm(3mil) |
|
8 |
Surface finish/treatment |
HALS/HALS lead free,Chemical tin,Chemical Gold,Immersion gold Inmersion Silver/Gold,Osp,Gold Plating |
|
9 |
Copper thickness |
0.5-4.0oz |
|
10 |
Solder mask color |
green/black/white/red/blue/yellow |
|
11 |
Inner packing |
Vacuum packing,Plastic bag |
|
12 |
Outer packing |
Standard carton packing |
|
13 |
Hole tolerance |
PTH:±0.076,NTPH:±0.05 |
|
14 |
Certificate |
UL,ISO9001,ISO14001,ROHS,CQC |
|
15 |
Profiling Punching |
Routing,V-CUT,Beveling |
|
16 |
Assembly Service |
Providing OEM service to all sorts of printed circuit board assembly |
Detailed Terms for Pcb Assembly
Technical requirement:
1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity.
Quote requirement:
1)Gerber file and Bom list
2)Clear pictures of pcb/ fpc/ pcba or pcba sample for us
3)The PCB specification: Copper thickness(18um or 35um?); Finished board thickness(0.8mm or 1.6mm?);
Surface treatment(lead-free HASL or immersion gold?)
4)Test method for PCB/PCBA
