Introduction:
Flex PCBs, also known as flexible printed circuits or flexible electronics, provide greater options for designers and engineers when assembling electronic circuits.
They are constructed from flexible, high-performance plastic material, usually polyimide, which enables the board to bend or "flex" during use. This flexibility opens them up to use in a wide range of applications.
Product Details:
Payment & Shipping Terms:
|
Finish Hole Size: | PTH +/-0.003'' ,NPTH +/-0.002 | Hole Position Accuracy: | +/-0.003 |
---|---|---|---|
Ring Annulus: | Min 0.1mm | Aspect Ratio: | Min 1 8 |
Solder Mask Rrgistration: | +/-0.003 | ||
High Light: | flexible printed circuit board,flex pcb board |
double layer pcb
There is professional pcb&pcba design group waiting for you! Also there is pcb&pcba factory producing for you! Welcome your inquiry!
We independently research and develop Internet control system, Internet numericalcontrol system, robot control system and produce hardware and software independently for control management etc.. Also supply clients SAS Marketing Automation. Door bell, car alarm, mobile solar charger design by us is most welcome products.
PCB Engineering Capacity
No. | Item | Spec |
1 | Layers | 1 to 24 layers |
2 | Max working panel area | 457 x 610 mm |
3 | Min board thickness | 4 layer: 0.40mm |
6 layer: 0.80mm | ||
8 layer: 1.00mm | ||
10 layer: 1.20mm | ||
4 | Min trace width | 0.10mm |
5 | Min spacing | 0.10mm |
6 | Min hole diameter | 0.20mm |
7 | Min Copper thickness in hole | 0.020mm |
8 | PTH size tolerance | ±0.05mm |
9 | NPTH size tolerance | ±0.025mm |
10 | Hole position tolerance | ±0.05mm |
11 | Dimension tolerance | ±0.1mm |
12 | Min solder mask dam | 0.08mm |
13 | Insulation resistance | 1E+12Ω (normal condition) |
14 | Max Board thickness/Hole size Rate | '10:1 |
15 | Thermal shock endurance | 288 3 times in 10sec |
16 | Max Board twist and wrap | ≤0.7% |
17 | High Vlotage endurance | 1.3KV/mm |
18 | Copper foil peel off endurance | 1.4N/mm |
19 | Hardness of resist ink | ≥6H |
20 | Flame resistance | 94V-0 |
21 | Impedance control | ±5% |
22 | Certificate |
ISO 9001:2000;ISO 14001;ISO/TS16949:2002 ,UL E203640 |
