Double sided circuit board means has a double-sided copper, and metallized holes, that is double-sided copper, and copper are holes inside
Both sides have double wiring board, but to use the wire on both sides. Both sides must be in the room with appropriate electrical connections. "Bridge" between this circuit called vias. Guide hole in the PCB, metal filled or coated with holes, which can be connected to the conductors on both sides. Because dual-panel area twice as big than the single panel, double panel to solve the single-panel wiring staggered because of difficulty (can be turned to the other side of the hole), it is more suitable for use in more complex than single-panel circuit.
Advantages
Compared with single-board: wiring convenient, simple, labor-intensive wiring smaller, shorter line length.
Double Circuit Board Design Steps
1. Prepare circuit schematics
2. Create a new file and loaded PCB component package library
3, planning board
4, into the network table and components
5, automatic layout components
6, layout adjustment
7, the network density analysis
8, wiring rules set
9, automatic routing
10, manually adjust the wiring
Product Details:
Payment & Shipping Terms:
|
Highlight: | quick turn pcb prototypes,double sided printed circuit board |
---|
Double Sided PCB Fabrication, FR4 PCB Material with Immersion Gold/ ENIG finishing
> Brand Name: East PCB
> Material: FR4
> Layer Count: 4 layers
> Board Thickness: 1.6 mm
> Copper Thickness: 1OZ
> Surface Finish: HASL
> Solder Mask: Green (top&bot)
> Silkscreen: White screen (top&bot)
> Min drill/pad: 0.3mm/ 0.5mm
> Other:
> Certification: UL, RoHS, ISO9001,
ISO14001, TS16949
Requirements and services including:
•Design, technical and advisory services
•Single and double sided (both NPTH and PTH)
•Multlayers
•Hot Tin/Lead Solder
•Lead Free- RoHS
•Gold or Silver Immersion
•Gold fingers
•Electroplated Copper, Tin or Silver
•SMT Stencils
•Peelable mask
•PCB panel laminate supply
•Light Sensitive film laminate
•Electrical testing
•V Scoring
•Budget Prototype Service
•International outsourcing
•UL Certication
•QA Conformance Certification
•Specialist plating thickness measurement certification
Main application:
> Security industry:
intelligent building system, video intercom, DVR, network camera, etc.
> Communication device:
CDMA device, switchboard, access network and broadband transmission facility, etc.
> Electrical equipment:
power monitoring equipment, power dispatching equipment, high-frequency switching power supply, etc.
> Network equipment:
Network server, router, VDSL, etc
> Computer equipment:
Industrial control computer, computer motherboard, etc
> Medical instrument:
Nuclear magnetic resonance instrument (MRI), CT, color Doppler, monitors, etc.
> Cutting-edge technology:
aerospace, missile, radar and other military products
> Consumer electronics:
Digital camera, MP3, car electronic
PCB Capability
NO | ITEM | Technical capabilities |
1 | Layers | 1-28 layers |
2 | Materials | FR4, Hi-TG, Rogers, FPC, Aluminum |
3 | Board Thickness | 0.2-5.0mm |
4 | Finished Copper Thickness | 1/2 OZ, 1-5 OZ |
5 | Min. line Width/Space | 0.1mm(4mil) |
6 | Min. S/M Pitch | 0.1mm(4mil) |
7 | Min. hole size | 0.2mm(8mil) |
8 | Solder mask color | green, blue, black, white, yellow, purple, etc |
9 | Silkscreen Color | white, black, yellow |
10 | Surface Finished | HAL(lead free), Immersion gold, OSP |
11 | Other Technology | Gold finger, peelable mask, Non-across blind/buried vias, characteristic impedance control, etc. |
12 | Reliability Test | flying probe test/fixture test, impedance test, solderability test, hole resistance test, etc. |
