Double Sided PCB

  • High Precision Double Sided PCB suppliers
  • High Precision Double Sided PCB suppliers





Introduction


Double sided circuit board means has a double-sided copper, and metallized holes, that is double-sided copper, and copper are holes inside

Both sides have double wiring board, but to use the wire on both sides. Both sides must be in the room with appropriate electrical connections. "Bridge" between this circuit called vias. Guide hole in the PCB, metal filled or coated with holes, which can be connected to the conductors on both sides. Because dual-panel area twice as big than the single panel, double panel to solve the single-panel wiring staggered because of difficulty (can be turned to the other side of the hole), it is more suitable for use in more complex than single-panel circuit.





Advantages


Compared with single-board: wiring convenient, simple, labor-intensive wiring smaller, shorter line length.





Double Circuit Board Design Steps



     1. Prepare circuit schematics

     2. Create a new file and loaded PCB component package library

     3, planning board

     4, into the network table and components

     5, automatic layout components

     6, layout adjustment

     7, the network density analysis

     8, wiring rules set

     9, automatic routing

     10, manually adjust the wiring



Hole Inspection Machine For PCB Testing Equipment , PCB tester machine

Hole Inspection Machine For PCB Testing Equipment , PCB tester machine
Hole Inspection Machine For PCB Testing Equipment , PCB tester machine Hole Inspection Machine For PCB Testing Equipment , PCB tester machine Hole Inspection Machine For PCB Testing Equipment , PCB tester machine

Large Image :  Hole Inspection Machine For PCB Testing Equipment , PCB tester machine

Product Details:

Place of Origin: China
Brand Name: ASIDA
Model Number: JK3600

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: Negotiation
Packaging Details: Wooden Carton
Delivery Time: 2Weeks
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: Negotiation
Detailed Product Description
Repeat Accuracy: Repeat Accuracy Model Number: JK3200/JK3600
Product Name: Hole Inspection Machine Inspection Speed: 6.5、10、12.5m/min(Adjustable)
High Light:

pcb board testing equipment

,

circuit board testing equipment

Drill Hole Automatic Inspection Equipment , PCB Tester Machine





Product Attributes:



Product name

 Hole Inspection Machine

Brand Name

ASIDA

Model Number

JK3200/3600

Place of Origin

China

Packaging Details

Wooden Carton



Usage



ASIDA-JK3600 Inspection Hole Machine is used to inspect completed PCBs for drill hole defects. The number and quality of drilled holes is checked and the board is assigned to be either OK or NG, the resulting PCBs are sorted accordingly.

Characteristics

  • User friendly interface, no special training required.

  • Long bar LED light source.

  • Detection speed can reach up to 12.5m/min.

  • 30 degree angle detection range, inputed boards can be off centre by up to 30 degrees.

  • Capable of checking two boards simultaneously.

  • Network maintenance function, can link to other systems to display OK/NG information.

  • Personalised software designed to specific customer requirements.

Efficient



①JK3200 is equipped with double sorting equipment, which can detect two plates at the same time.

②JK3600 is equipped with six sorting equipment,which can detect six plates at the same time.



Hole Checker Client:

Accuracy

①Repeat accuracy:±40µm

②Measurement Accuracy:±40µm

Inspection Speed

6.5,10,12.5m/min(Adjustable)

Objects

① Aperture range:0.15~10mm

②Size of measurable boards:100×150~630×650mm

③ Thickness range of measurable boards:0.3~10mm

④Hole margins:≥0.15mm

Dimensions

3550*1200*1100mm

Weight

400-450Kg

Hole Inspection Machine For PCB Testing Equipment , PCB tester machineHole Inspection Machine For PCB Testing Equipment , PCB tester machine
