1. Rigid-flexible pcb board for infrared camera
2. This rigid- flexible pcb board shows how designers use flex to reduc
Rigid- flexible pcb board
This is another pure flex package; 14 layers
bonded with flexible bond plies; controlled
depth laser vias on the outer three layers of
each side.
Application: Infrared Camera
Size: 6.6 by 1.6
Layers: 14 overall, pure flex
Materials: Adhesiveless flex
Adhesive bond plies and coverlay
Traces: 4/4 innerlayers
4/4 outerlayers
Minimum hole: 0.06
Minimum pad: 0.12
Thickness: 0.60
Other: Controlled depth laser vias
3/8/3 construction
5 Lamination cycles
Silver epoxy shielding
Our Production Capability for PCB
- Layer: 1 to 28 layers
- Material type: FR-4, CEM-1, CEM-3, High TG, FR4 Halogen Free, Rogers
- Board thickness: 0.21mm to 7.0mm
- Copper thickness: 0.5 OZ to 7.0 OZ
- Copper thickness in hole: >25.0 um (>1mil)
- Size:
- Max. Board Size: 23 × 25 (580mm×900mm)
- Min. Drilled Hole Size: 3mil (0.075mm)
- Min. Line Width: 3mil (0.075mm)
- Min. Line Spacing: 3mil (0.075mm)
- Surface finishing: HASL / HASL lead free, HAL, Chemical tin, Chemical Gold, Immersion Silver/Gold, OSP, Gold plating
- Solder Mask Color: Green/Yellow/Black/White/Red/Blue
- Tolerance
- Shape tolerance: ±0.13
- Hole tolerance: PTH: ±0.076 NPTH: ±0.05
- Inner packing: Vacuum packing / Plastic bag
- Outer packing: Standard carton packing
- Certificate: UL, ISO 9001, ISO 14001
- Special requirements: Buried and blind vias+controlled impedance +BGA
- Profiling: Punching, Routing, V-CUT, Beveling
- Provides OEM services to all sorts of printed circuit board assembly as well as electronic encased products.
Contact us to check out great PCBs and full details, we will reply to you with prices in one working day!
- OEM services provided
- Certificate: ROHS, UL, ISO9001-2000, ISO14001
- Factory direct price
