Rigid Flex PCB

  • High Precision Rigid Flex PCB suppliers
  • High Precision Rigid Flex PCB suppliers

Introduction


Rigid flex printed circuit boards are boards using a combination of flexible and rigid board technologies in an application. Most rigid flex boards consist of multiple layers of flexible circuit substrates attached to one or more rigid boards externally and/or internally, depending upon the design of the application. The flexible substrates are designed to be in a constant state of flex and are usually formed into the flexed curve during manufacturing or installation.

Rigid flex designs are more challenging than the design of a typical rigid board environment, as these boards are designed in a 3D space, which also offers greater spatial efficiency. By being able to design in three dimensions rigid flex designers can twist, fold and roll the flexible board substrates to achieve their desired shape for the final application's package.





Production Process


Whether producing a rigid flex prototype or production quantities requiring large scale rigid flex PCB fabrication and PCB assembly, the technology is well proven and reliable. The flex PCB portion is particularly good in overcoming space and weight issues with spatial degrees of freedom.

Careful consideration of flex-rigid solutions and a proper assessment of the available options at the early stages in the rigid flex PCB design phase will return significant benefits. It is critical the rigid flex PCB fabricator is involved early in the design process to ensure the design and fab portions are both in coordination and to account for final product variations.

The rigid flex manufacturing phase is also more complex and time consuming than rigid board fabrication. All the flexible components of the rigid flex assembly have completely different handling, etching and soldering processes than rigid FR4 boards.






Applications


Rigid flexible PCBs offer a wide array of applications, ranging from military weaponry and aerospace systems to cell phones and digital cameras. Increasingly, rigid flex board fabrication has been used in medical devices such as pacemakers for their space and weight reduction capabilities. The same advantages for rigid flex PCB usage can be applied to military weaponry and weapon control systems.

In consumer products, rigid flex doesn't just maximize space and weight but greatly improves reliability, eliminating many needs for solder joints and delicate, fragile wiring that are prone to connection issues. These are just some examples, but rigid flex PCBs can be used to benefit nearly all advanced electrical applications including testing equipment, tools and automobiles. Not sure what technology needs to be used for your project? Call our experts and we can help you figure out whether you need rigid flex, flex or HDI PCB technology.

Rigid Flexible PCB Single Side Turnkey PCB Assembly 100% E-Test

Rigid Flexible PCB Single Side Turnkey PCB Assembly 100% E-Test
Rigid Flexible PCB Single Side Turnkey PCB Assembly 100% E-Test

Large Image :  Rigid Flexible PCB Single Side Turnkey PCB Assembly 100% E-Test

Product Details:

Place of Origin: China
Brand Name: HUASWIN
Certification: ISO/UL/RoHS
Model Number: HSPCBA1003

Payment & Shipping Terms:

Minimum Order Quantity: 1 sets
Price: Negotiation
Packaging Details: Anti-static bag + Anti-static bubble wrap + Good quality carton box
Delivery Time: 15-20 working days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 10,000pcs per month
Detailed Product Description
High Light:

pc board assembly

,

printed circuit board assembly



Rigid Flexible PCB Single Side Turnkey PCB Assembly Manufacturer





Specifications



1. Electronics PCB and PCB assembly manufacturer
2. UL,RoHS,SGS, ISO Approved
3. Reliable OEM / ODM PCB assembly
4. High Quality, fast delivery

5. Best after-sales service





PCB capability and services:


1. Single-sided, double-sided & multi-layer PCB (up to 30 layers)

2. Flexible PCB (up to 10 layers)

3. Rigid-flex PCB (up to 8 layers)

4. CEM-1, CEM-3 FR-4, FR-4 High TG, Polyimide, Aluminum-based material.
5. HAL, HAL lead free, Immersion Gold/ Silver/Tin, Hard Gold, OSP surface treatment.
6. Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB standard.
7. Quantities range from prototype to volume production.
8. 100% E-Test





Detailed Specification of PCB Manufacturing



1

layer

1-30 layer

2

Material

CEM-1, CEM-3 FR-4, FR-4 High TG, Polyimide, Aluminum-based

 material.

3

Board thickness

0.2mm-6mm

4

Max.finished board size

800*508mm

5

Min.drilled hole size

0.25mm

6

min.line width

0.075mm(3mil)

7

min.line spacing

0.075mm(3mil)

8

Surface finish

HAL, HAL Lead free,Immersion Gold/ Silver/Tin, Hard Gold,

OSP

9

Copper thickness

0.5-4.0oz

10

Solder mask color

green/black/white/red/blue/yellow

11

Inner packing

Vacuum packing,Plastic bag

12

Outer packing

standard carton packing

13

Hole tolerance

PTH:±0.076,NTPH:±0.05

14

Certificate

UL,ISO9001,ISO14001,ROHS,TS16949

15

Profiling punching

Routing,V-CUT,Beveling




PCB Assembly services:



SMT Assembly
Automatic Pick & Place
Component Placement as Small as 0201
Fine Pitch QEP - BGA
Automatic Optical Inspection

Through-hole Assembly
Wave Soldering
Hand Assembly and Soldering

Material Sourcing
IC pre-programming / Burning on-line

Function testing as requested

Aging test for LED and Power boards

Complete unit assembly (which including plastics, metal box, Coil, cable assembly etc)
Packing design





Testing Methods

AOI Testing
Checks for solder paste
Checks for components down to 0201"
Checks for missing components, offset, incorrect parts, polarity

X-Ray Inspection
X-Ray provides high-resolution inspection of:
BGAs
Bare boards

In-Circuit Testing
In-Circuit Testing is commonly used in conjunction with AOI minimizing functional defects caused by

component problems.
Power-up Test
Advanced Function Test
Flash Device Programming
Functional testing





Factory view:
