Testing Procedures For PCB Board
---We perform multiple quality assuring procedures before shipping out any PCB board. These include:
* Visual Inspection
* Flying probe
* Bed of nails
·* Impedance control
·* Solder-ability detection
* Digital metallograghic microscope
·*AOI (Automated Optical Inspection)
Detailed Terms for PCB Manufacturing
---Technical requirement for pcb assembly:
* Professional Surface-mounting and Through-hole soldering Technology
* Various sizes like 1206,0805,0603 components SMT technology
* ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
* PCB Assembly With UL,CE,FCC,Rohs Approval
* Nitrogen gas reflow soldering technology for SMT.
* High Standard SMT&Solder Assembly Line
* High density interconnected board placement technology capacity.
Surface Treatment
Lead-free HAL
Gold Plating (1-30 micro inch)
OSP
Silver Plating
Pure Tin Plating
Immersion Tin
Immersion Gold
Gold Finger
Other Service:
A) We have many special material as rogers, teflon, taconic, Fr-4 high tg, Ceramic in stock. Welcome to send us your inquiry.
B) We also provide sourcing components , PCB design , PCB copy , PCB drawing , PCB assembly and so on .
|
Product Details:
Payment & Shipping Terms:
|
| High Light: | Aluminum base PCB,LED pcb,single side pcb |
||
|---|---|---|---|
| Base Material | aluminum |
| Copper Thickness | 1 Oz |
| Board Thickness | 1.6mm |
| Min. Hole Size | 0.3mm |
| Min. Line Width | 0.2mm |
| Min. Line Spacing | 0.2mm |
| Surface Finishing | Gold finger |
| is_customized | Yes |
The following is a list of the services and products we offer:
FR4 Printed circuit boards
1.Single Sided through 48-Layer
2.Blind/Buried Via Configurations
3.Heavy copper up to 10 oz
4.control Impedance PCB
5.High Frequence PCB
Metal clad substrate technology
1.Single sided Aluminum PCB
2.Double sided Aluminum PCB
3.FR4+Aluminum mixed backed circuit boards
4.Copper substrate PCB
Please send email to
sales01(at)fastlinepcb.com
We also provide PCB assembly service and Buy components service to customer for saving time and money.
Remark:
If you have the PCB file, we can make the PCB for you soon.
Please kindly send us your PCB files (Gerber/Protel/CAM/Eagle) for final quotation.
If you have not gerber file now, but you could got CAD or draw pictures,
we also could make PCB layout design for you.
These are only reference info, not the final prices and PCB images.
All PCBs are custom design.
How to get a quotation from us?
In order to enable us to make you a quotation, please provide me below information.
1. PCB Files
Please send me your PCB files in Gerber/Protel/CAM/Eagle or CAD or draw pictures.
2. Available PCB Base Material:
FR4 1.6mm, FR4 1.2mm, FR4 1.0mm, FR4 0.8mm, Aluminium 1.6mm or other
3. Available Copper Thickness:
0.5oz, 1oz, 2oz, 3oz, 4oz
4. Surface Treatment
Immersion Gold Over Nickle, HASL Lead Free, OSP
5. Available Colors for Solder Mask and Top Overlay(Component Legend)
Green, Blue, Red, Black, White
6. Your accurate address
One example of common specification for PCB is as below:
FR4 1.6mm, ROHS, 1/1oz, Immersion Gold over Nickle, Green Solder Mask, White Top Overlay
quantity , And your address
Lead Time:
For small quantity prototypes, it takes about 3~4 days for us to ship the goods out.
For some hard PCB and batch production, it takes about 7 days for shipment.
For PCB assembly, it takes about 10 days for shipment.
Contact us!
Contact Person: Miss. aaa
Tel: 86 755 8546321
Fax: 86-10-66557788-2345
