Full Color Video Led Outdoor Display Board With 2R1G1B / VGA , DVI Input Signal

Large Image : Full Color Video Led Outdoor Display Board With 2R1G1B / VGA , DVI Input Signal

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	Meltonled
Certification:	CE, RoHS, ISO,FCC,UL
Model Number:	P16-318

Payment & Shipping Terms:

Minimum Order Quantity:	1pc/1sqm
Price:	600usd
Packaging Details:	Anti-shaking wooden case/flight case/carton
Delivery Time:	7-15 days
Payment Terms:	35% T/T as prepayment,65% T/T as balance at factory, Western Union, MoneyGram
Supply Ability:	>500sqm/month
Delivery term:	Ex-work/FOB/CIF/DDU

Contact Now

Detailed Product Description

Product Name:	Outdoor Full Color Led Display	Usage:	Advertising
Tube Chip Color:	Full Color	Pixel Pitch:	16mm
Pixel Configeration:	1R,1G,1B	Cabinet Pixel:	4096
Brightness:	10000cd
Highlight:	digital led display board , video display boards

Full Color Video Led Outdoor Display Board With 1R1G1B / VGA , DVI Input Signal

Specifications

1) System structure

Full Color Video Led Outdoor Display Board With 2R1G1B / VGA , DVI Input Signal

2)Led Module

Module Size(W * H)	256mm*256mm	Pixel Configeration	1R,1G,1B
Pixel Pitch	16mm	Resolution(W*H)	16dots*16dots
Pixel Density	3906 dot / m²	Driving Method	static Current

3)Led cabinet

Cabinet Size(W * H)	1024mm*768mm	Module Qty	20pcs
Cabinet Resolution(W * H)	64dots*48dots	Cabinet Pixel	4096
Weight	50kg/pc	Area	1.23(m²)
Avarage Power Consumption	600W/m²	Max Consumption	1000W/m²

4)Led Video wall technical parameter

Operating Humility	10% ~ 90% RH
Oprating Temprature	-30°C ~ +60°C
Optimal Viewing Distance	10m-60m
Display Color	1,070,000,000
Gray Scale	65536grade
Brightness control	256grade
Frame Frequency	60HZ
Refresh Speed	>3840HZ
Power Supply	220V/50HZ
MTBF	≥10,000hours
Life Span (50% brightness)	≥100,000hours
Control Mode	synchronization with PC
Input Signal Format	VGA,DVI,RGBHV,PbPr(HDTV),Composite,S-Video,TV
Operating System	WINDOWS(98,2000,XP,Vista)

Methods for Quality Assurance

a. Aging

1. 100% fully test

2. Condition: 72 hours with 256 grey level

b. Vibration Testing

Condition: 3-5 mins up and down in 5mm range

Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.

Package

Flight case and Fumigation-Free wooden case

Competitive Advantage:

1. 2 years’ warranty with free repair service

2. 24/7 Hours online Remote Support

3. Solution and PCB design

4. Free factory training

5. Onsite installation instruction and regular inspection

6, Small order accepted.
