3.7V 1250mAh Rechargeable Lithium Batteries Flat Prismatic Cell With PCB For Wireless Facilties
Quick Detail:
-
Voltage: 3.7V
-
Capacity: 1250mAh
-
dimension: 8*34*50mm
-
Standard charge and discharge at 1C
-
OEM/ODM Service offered,
-
Battery pack With PCM , Charger, Aluminum case
-
12months warranty
-
long cycle life
-
reliable performance
-
better temperature characteristics
-
Tags, plugs and connectors are available
Feature:
-
Ultra thin
-
No Pollution
-
Longer life cycle
-
Ultra light weight
-
High energy density
-
High powerdensity
-
Higher safety performance
-
Special polymer separator using
-
Most advanced technology battery.
Applications:
-
PDA, RC toys, MP3/MP4, Camcorde, walkmans,
-
DVD, VCD, cordless phone, celluar phone,
-
two-way radio, Smoke alarm, gas detector
-
Notebook , Video DVD, R/C planes
-
Mobile phone, Digital camera
-
Bluetooth headsets, Wireless mouse and other device
-
Electric vehicle, Solar car
-
UPS, Electric bicycle
-
Electric scooter, Golf trolley
-
Electric wheel chair, Electric boat
-
Cleaner, Grass cutter, vacuum cleaners
-
Submarine, Unmanned air vehicle
-
Medical and military use
-
Robotics
-
Wireless facilties
Products Photos:
Specifications:
|
Item
|
TY-803450
|
|
Type
|
Lithium polymer Battery
|
|
Nominal Capacity
|
1250mAh
|
|
Nominal Voltage
|
3.7V
|
|
Maximum charge current
|
4.2V
|
|
Cut-off voltage
|
3.0V
|
|
Standard charge current
|
0.2C
|
|
Standard discharge current
|
1C
|
|
Max continuous discharge current
|
2C
|
|
Dimension
|
8.0*34*50mm
|
|
Weight
|
26g
|
|
Cycle life (80DOD%)
|
≥500times
|
|
Operating temperature
|
Charge: 0°C~45°C
Discharge: -20°C~60°C
|
Competitive Advantage:
-
Green product ,Pollution-free
-
High energy density
-
Long standby time
-
One year warranty
-
Excellent safety performance
-
Excellent storage performance and low self-discharge rate
-
Short circuit testing passed
-
Overcharge testing passed
-
Over discharge testing passed
-
Thermal shock test passed
-
Factory price& High quality
-
Light weight, small size
TONGYU Lithium polymer battery cell part model
|
Model
|
Nominal Voltage
|
Capacity
|
Dimension
|
Weight Approx
|
|
(V)
|
Typical (mAh)
|
T(± 0.2) x W(± 0.5) x H(± 1)(mm)
|
(g)
|
|
TY802835
|
3.7
|
750
|
8*28*35
|
14.6
|
|
TY702840
|
3.7
|
800
|
7*28*40
|
15.6
|
|
TY702851
|
3.7
|
1000
|
7*28*51
|
19.5
|
|
TY602937
|
3.7
|
600
|
6*29*37
|
11.5
|
|
TY1029101
|
3.7
|
3100
|
10*29*101
|
62.5
|
|
TY603030
|
3.7
|
480
|
6*30*30
|
8.8
|
|
TY503040
|
3.7
|
560
|
5*30*40
|
10.8
|
|
TY503048
|
3.7
|
700
|
5*30*48
|
14
|
|
TY643093
|
3.7
|
1800
|
6.4*30*93
|
35.1
|
|
TY6530100
|
3.7
|
2100
|
6.5*30*100
|
40.9
|
|
TY6830150
|
3.7
|
2800
|
6.8*30*150
|
54.5
|
|
TY033140
|
3.7
|
340
|
3.1*31*41
|
6.5
|
|
TY0831134
|
3.7
|
4000
|
8.1*31*132
|
68.2
|
|
TY413239
|
3.7
|
460
|
4.1*32*39
|
8.9
|
|
TY0932100
|
3.7
|
2650
|
8.8*32*100
|
51.6
|
|
TY053347
|
3.7
|
780
|
5.0*33*47
|
15
|
|
TY083365
|
3.7
|
1800
|
8.0*33*65
|
35
|
|
TY083375
|
3.7
|
2100
|
8.0*33*75
|
41
|
|
TY033436
|
3.7
|
320
|
3.1*34*36
|
6.8
|
|
TY103444
|
3.7
|
1500
|
10*34*44
|
29.2
|
|
TY083448
|
3.7
|
1250
|
7.8*34*48
|
24.5
|
|
TY563452
|
3.7
|
650
|
3.8*34*52
|
12.8
|
|
TY383458
|
3.7
|
780
|
3.8*35*62
|
14.6
|
|
TY063450
|
3.7
|
1350
|
6.0*34*50
|
26
|
|
TY653480
|
3.7
|
1800
|
6.4*34*80
|
35.1
|
|
TY383562
|
3.7
|
800
|
3.8*35*62
|
16
|
|
TY033645
|
3.7
|
420
|
3*36*45
|
8.1
|
|
TY5536110
|
3.7
|
2200
|
5.6*36*110
|
42.5
|
|
TY853740
|
3.7
|
1200
|
8.5*37*41
|
23.4
|
|
TY353753
|
3.7
|
700
|
3.5*37*53
|
13.2
|
|
TY053759
|
3.7
|
1200
|
5.0*37*59
|
23
|
|
TY073767
|
3.7
|
1800
|
7*37*67
|
35
|
|
TY553775
|
3.7
|
1500
|
5.5*37*75
|
29.5
|
|
TY093868
|
3.7
|
2500
|
9*38*68
|
48
|
|
TY063954
|
3.7
|
1300
|
5.8*39*54
|
25
|
|
TY824040
|
3.7
|
1100
|
7*40*40
|
19.5
|
|
TY554050
|
3.7
|
1100
|
5.5*40*50
|
21.5
|
|
TY754065
|
3.7
|
1800
|
6*40*67
|
35
|
|
TY0540150
|
3.7
|
3500
|
5.1*43*153
|
66
|
|
TY554163
|
3.7
|
1500
|
5.5*41*63
|
29
|
|
TY074374
|
3.7
|
2300
|
7*43*74
|
44.8
|
|
TY824452
|
3.7
|
2000
|
8.2*44*52
|
38.5
|
|
TY584466
|
3.7
|
1800
|
6*44*66
|
33.5
|
|
TY0845131
|
3.7
|
5100
|
7.5*45*131
|
98.8
|
|
TY054795
|
3.7
|
1900
|
5*47*95
|
37
|
|
TY054854
|
3.7
|
1500
|
5.5*48*54
|
29.5
|
|
TY304860
|
3.7
|
850
|
3.1*48*60
|
16.5
|
|
TY555057
|
3.7
|
1850
|
5.7*50*57
|
35.5
|
|
TY055060
|
3.7
|
1550
|
5*50*60
|
29.5
|
|
TY085065
|
3.7
|
2600
|
8*50*65
|
50.5
|
|
TY055070
|
3.7
|
1800
|
5*50*70
|
35
|
|
TY085080
|
3.7
|
3400
|
8*50*80
|
65
|
|
TY055085
|
3.7
|
2100
|
5*50*85
|
40
|
|
TY055090
|
3.7
|
2500
|
5.2*50*90
|
48
|
|
TY545256
|
3.7
|
1700
|
5.5*52*56
|
33
|
|
TY555376
|
3.7
|
2300
|
5.6*53*76
|
44
|
|
TY035565
|
3.7
|
1000
|
3*55*65
|
19.4
|
|
TY085575
|
3.7
|
3400
|
7.5*55*75
|
65
|
|
TY035590
|
3.7
|
1500
|
3.2*55*90
|
29
|
|
TY055862
|
3.7
|
1950
|
5*58*62
|
38
|
|
TY456080
|
3.7
|
1600
|
4.2*60*80
|
40
|
|
TY356093
|
3.7
|
2100
|
3.6*60*93
|
40.9
|
|
TY066166
|
3.7
|
2750
|
6*61*66
|
53
|
|
TY356493
|
3.7
|
1800
|
3.5*64*93
|
35.1
|
|
TY0567100
|
3.7
|
3400
|
4.9*67*100
|
65
|
|
TY0790210
|
3.7
|
10000
|
7*90*210
|
275
|
|
TY8867220
|
3.7
|
10000
|
8.8*67*220
|
265
|
|
TY7067220
|
3.7
|
10000
|
7.0*67*220
|
260
|
|
TY1665130
|
3.7
|
10000
|
16*65*130
|
260
|
|
TY13067140
|
3.7
|
10000
|
13*67*140
|
260
|
Note: any other size and capacity can not find in the index, please check with TONGYU, please email to us at info@tongyu-tech.com
We could design and produce the battery pack (plastic shell, Alu shell, or PVC Shrink Wrapped) and assembly procession for customized configurations is available.
