Introduction
PCB Assembly is a process that requires knowledge not just of PCB components and assembly but also of printed circuit board design, PCB fabrication and a strong understanding of the final product. Circuit board assembly is just one piece of the puzzle to delivering the perfect product the first time.
San Francisco Circuits is a one-stop solution for all circuit board services so we are often entrenched with the PCB production process from design to assembly. Through our strong network of well-proven circuit assembly and manufacturing partners, we can provide the most advanced and nearly limitless capabilities for your prototype or production PCB application. Save yourself the trouble that comes with the procurement process and dealing with multiple components vendors. Our experts will find you the best parts for your final product.
PCB Assembly Services:
Quick-turn prototype assembly
Turn-key assembly
Partial turn-key assembly
Consignment assembly
RoHS compliant lead-free assembly
Non-RoHS assembly
Conformal coating
Final box-build and packaging
PCB Assembly Process
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing
Testing Services
X-Ray (2-D and 3-D)
BGA X-Ray Inspection
AOI Testing (Automated Optical Inspection)
ICT Testing (In-Circuit Testing)
Functional Testing (at the board & system level)
Flying Probe
Capabilities
Surface Mount Technology / Parts (SMT Assembly)
Through-Hole Device / Parts (THD)
Mixed Parts: SMT & THD assembly
BGA / Micro BGA / uBGA
QFN, POP & lead-less chips
2800 pin-count BGA
0201 / 1005 passive components
0.3 / 0.4 Pitch
PoP Package
Flip-chip under-filled CCGA
BGA Interposer / Stack-up
and more…
Product Details:
Payment & Shipping Terms:
|
| High Light: | pcb board assembly |
||
|---|---|---|---|
Product Description:
XCE PCB technical specifications | |
Annual stock Material | Rogers,Taconic,Arton,Isola,F4B,TP-2.FR-4,High TG,Halogen free |
Layer No. | 1~16 |
Min board thickness | 2 layer0.2mm 4 layer0.4mm 6 layer 0.6mm 8 layer 0.8mm 10 layer 1.0mm |
Max panel size | 508*610mm |
Board thickness tolerance | T≥0.8mm±8%.,T<0.8mm±5% |
Wall hole copper thickness | >0.025mm(1mil) |
Finished hole | 0.2mm-6.3mm |
Min line width | 4mil/4mil(0.1/0.1mm) |
Min bonding pad space | 0.1mm(4mil) |
PTH aperture tolerance | ±0.075mm(3mil) |
NPTH aperture tolerance | ±0.05mm(2mil) |
Hole site deviation | ±0.05mm(2mil) |
Profile tolerance | ±0.10mm(4mil) |
Board bend&warp | ≤0.7% |
Insulation resistance | >1012Ωnormal |
Through-hole resistance | <300Ωnormal |
Electric strength | >1.3kv/mm |
Current breakdown | 10A |
Peel strength | 1.4N/mm |
Soldmask regidity | >6H |
Thermal stress | 288℃20Sec |
Testing voltage | 50-300V |
Min buried blind via | 0.2mm(8mil) |
Outer copper thickness | 1oz-5oz |
Inner cooper thickness | 1/2 oz-4oz |
Aspect ratio | 8:1 |
SMT min green oil width | 0.08mm |
Min green oil open window | 0.05mm |
Insulation layer thickless | 0.075mm-5mm |
Taphole aperture | 0.2mm-0.6mm |
Special technology | Indepedance,Blind buried via,thick gold,aluminum PCB |
Surface finish | HASL,Lead free HASL,Immersion Gold, Immersion Tin, Immersion Silver,OSP ,ENIG ,Golden finger,Blue glue,Gold plating |
Appilication:
a Telecom: transmitter. Receiver. Oscillator. Antenna.
b Satellite receiver
c Global location system, amplifier, satellite telecom
d Microwave transmission
e Automobile telephone
f Measure apparatus, LSI inspector, analyser, signal oscillator
g High frequency teletcom, high speed transmission, high security, high transmission quality, high memory transaction
Hot-Sale Poducts:
FAQ:
Q:Are you a manufacturer?
A:Yes.
Q:How about your delivery time?especially for sample?
A:Normally,it will take 3 to 10 days.to expedite quick samples within 24 hours is available and extra charges will be on your account for the service.
Q:What is your advantage?
A:Prompt delivery,high quality,sufficient stock base.
Q:What is your M.O.Q?
A: Our M.O.Q is 1pcs.
Q: Can you provide us best price?
A: As a manufacturer,we have strong capability to provide you costdown solutions and more competitive prices thanthe trading company.
Q: How do you ship the goods and how long does it take?
A: We dispatch the goods to our customers by DHL,UPS,FedEx or TNT express.usually,it takes 3-5 days to arrive.
Q: What file we should offer?
A: Making PCB should offer gerber file of the bare PCB board (protel ,power pcb,PADs file).
Q:Can we visit your factory?
A: We welcome you paying us a visit at any time.we look foward to your arrival and valuable instructions in the near future.
