Introduction:
Focus on the most basic of PCB, components focused on one side, the other side of the wire is concentrated.Because wires only appear on one side, so this kind of PCB is called single sided PCB.
Single panel wiring diagram is given priority to with the network printing, that is, in the copper surface printed on resistance agent, to prevent welding resistance after etching printed on mark, and then punching processing way to complete the parts guide hole and the appearance.In addition, part of a small amount of diverse products, are using photosensitive resistance agent forming pattern of the photographic method.
Operating temperatures range from 130 C to 230 C. Single sided boards are available with surface finishes including Organic surface protectant (OSP), Immersion Silver, Tin, and Gold plating along with both leaded or lead-free Hot Air Solder Level (HASL).
Material:
Single sided PCB base material in paper phenolic copper paper laminated board, epoxy resin copper laminated plate is given priority to.
Structure:
First, the copper foil to be etched, etc. Process to obtain a circuit required, a protective film to be drilled to expose the corresponding pad. After cleaning and then rolling method to combine the two. Then the pad portion exposed gold plating or tin protection.
Production Process:
Single copper-clad plate - blanking - photochemical method/screen printing image transfer - remove corrosion was printed - cleaning, dry - hole machining - shape - dry cleaning - printing resistance welding coating - cure - printing mark symbol - cure - dry cleaning drying - pre coated flux - a finished product
Application
Single sided PCB most use in the radio, heating machine, cold storage, washing machines and other electrical appliances product, as well as the printer, vending machines, LED lighting, electronic components, such as commercial machine circuit
Product Details:
Payment & Shipping Terms:
|
Base Material: | FR4 | Copper Thickness: | 1 Oz |
---|---|---|---|
Board Thickness: | 1.6mm | Min. Hole Size: | 3 Mil |
Min. Line Width: | 3 Mil | Min. Line Spacing: | 3 Mil |
Surface Finishing: | HASL(lead Free) | ||
High Light: | single sided board,single sided printed circuit boards |
1.Single layer PCB manufacture
2.HASL lead free Single layer PCB
3.Single layer PCB design
4.PCB Assembly
5.FR4 material
OEM Shenzhen Single layer PCB manufacture Service | |||||||
1.Electronic Single layer PCB manufacturer+PCB Assembly(OEM service and PCBA supply) | |||||||
2.Components on PCB(Single layer PCB manufacturer) sourcing and purchasing | |||||||
3.STM Pick and Place Machine 11 sets | |||||||
4.Enclosure design and producttion Plastic injection mould | |||||||
OEM/ODM/EMS Servises for PCBA: | |||||||
1.PCBA.PCB assembly;SMT & PTH & BGA | |||||||
2.PCBA and enclosure design | |||||||
3.Components sourcing and purchasing | |||||||
4.Quick prototyping | |||||||
5.Plastic injection moulding | |||||||
6.Metal sheet stamping | |||||||
7.Final assembly | |||||||
8.Test:AOI,In-Circuit Test(ICT),Functional Test(FCT) | |||||||
9.Custom clearance for material importing and product export | |||||||
PCBA Capacity: | |||||||
SMT: 2,000,000 solder joints per day | |||||||
DIP: 300,000 joints per day | |||||||
Orientronic SMT Production Flow: | |||||||
Material Receiving - IQC - Stock - Material to SMT - SMT Line Loading - Solder Paste/Glue Printing - Chip Mount - Reflow - 100% Visual Inspection - Automated Optical Inspection (AOI) - SMT QC Sampling - SMT Stock - Material to PTH - PTH Line Loading - Plated Through Hole - Wave Soldering - Touch Up - 100% Visual Inspection - PTH QC Sampling - In-Circuit Test (ICT) - Final Assembly - Functional Test (FCT) - Packing - OQC Sampling - Shipping | |||||||
Requested information for PCB assembly: | |||||||
1. Gerber file of the bare PCB board | |||||||
2. BOM (Bill of material) for assembly | |||||||
To short the lead time, please kindly advise us if there is any acceptable components substitution. | |||||||
3. Testing Guide & Test Fixtures if necessary | |||||||
4. Programming files & Programming tool if necessary | |||||||
5. Schematic if necessary |
