1) Fast PCB with in 12 hours, 24 hours and 48 hours are available.
2) No MOQ for PCB ,PCBA ,FPC and Alu pcb.
3) Boards are RoHS compliant with UL.
4) Engineers with over 10 years of working experience can offer you professional suggestions.
5) Factory production Capability of 15000 sqm/month.
6) Quality inspection standard: IPC-6012 Class II.
7) Base material: FR4, Hi-tg FR4, Aluminum, High frequency (Rogers, Taconic, F4B, Arlon etc.), PI, PET.
HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink
1.Embedded high performance industrial motherboard. (2.0cm ultrathin)
2.DDR3 1066/1333/1600MHz memory,SO-DIMM socket maximum up to 4GB.
3.Support WIFI,3G SIM card,dual 1000M RJ45 LAN port,support Mini SATA SSD ,more efficiency.
4.Support power booting/plug and play,Timer-power-on.
5.Support 1080P HDMI resolution maximum up to:1920*1200;Support 24bit dual channel LVDS;VGA resolution maximum up to:2048*1536.
6.Reliable, High stability, Low noise, low power consumption.Perfectly suitable for AD Player/AIO machine/IPC/VOD/Car PC/HTPC etc.
Industrial Control PCB Specification
• ATMEL AT91SAM9G45, ARM926EJ-S Core
DDR RAM Memory
• 128MB DDR2 RAM, 133MHz, 32bit data bus
• On-board 512K DataFlash (DB45041D)
• On-board 128M*8bits NandFlash (K9F1G08U0B)could change a large capacity or industrial chip according to customer's requirement
• 2*100 pin 0.8mm spacing B to B(the connectors are 350°C high temperature-tested and seismic-tested)
Other Onboard Resources
• DM9161 net chip, support 10M/100M Ethernet with MII mode, more compatible than RMII;
• 1.8V, 3.3V, 5.0V voltage input
PCB Specification & Size
• Using six floors of PCB high precision process, and has the best electrical properties and anti-jamming performance
• 74 x 53 x 1.5mm
• Working temperature: -20°C~ 70°C (batch user could customize -40°C~ 85°C)
• Humidity Range: 5%~ 95%, Non-Condensing
Low Power Consumption
• 5v Dc power supply, low power consumption, <1W
Payment & Shipping Terms:
printed circuit board industry,
printed circuit assemblies
Our PCB board manufacture and PCB assembly service:
o PCB board file with parts list provided by customers
o PCB board made, circuit board parts purchased by us
o PCB board with parts assembled
o Electronic testing circuit board or PCBA
o Fast delivery, anti-static package
o RoHS Directive-compliant, lead-free
o One stop service for PCB design, PCB layout, PCB manufacture, components purchasing,
PCB assembly, test, packing and PCB delivery
Technical Specification For PCB
|Number of Layer||1,2,4 or 6,upto 18 layer|
|Order Quantity||1 to 50,000|
|Board Type||Rigid, Flexible, Rigid-flexible|
|Board Material||FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc.|
|Board Thickness||0.2-4.0mm, Flex 0.01-0.25mm|
|Copper Weight||1.0, 1.5, 2.0 oz|
|Solder Mask||Double-sided green LPI,Also support Red,White,Yellow,Blue,Black|
|Silk Screen||Double-sided or single-sided in white,yellow,black,or negative|
|Silk Screen Min Line Width||0.006'' or 0.15mm|
|Max Board Dimensions||20 inch*20inch or 500mm*500mm|
|Min Trace/Gap||0.10mm, or 4mils|
|Min Drill Hole Diameter||0.01'',0.25mm, or 10mils|
|Surface Finish||HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc.|
|Board Thickness Tolerance||±10%|
|Copper Weight Tolerance||± 0.25 oz|
|Minimal Slot Width||0.12'', 3.0mm, or 120mils|
|V-Score Depth||20-25% of board thickness|
|Design File Formate||Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG|
PCB Assembly Capabilities
|Quantity||Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000|
|Type of Assembly||SMT,Thru-hole|
|Solder Type||Water Soluble Solder Paste,Leaded and Lead-Free|
Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
|Bare Board Size||
Bill of Materials
|Types of Service||Turn-key,partial turn-key or consignment|
|Component packaging||Cut Tape,Tube,Reels,Loose Parts|
|Turn Time||Same day service to 15 days service|
|Testing||Flying Probe Test,X-ray Inspection AOI Test|
|PCB assembly process||
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing
Detailed Terms for Pcb Assembly
Technical requirement for pcb&pcb assembly:
---- Professional Surface-mounting and Through-hole soldering Technology
---- Various sizes like 1206,0805,0603 components SMT technology
----ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
----PCB Assembly With UL,CE,FCC,Rohs Approval
----Nitrogen gas reflow soldering technology for SMT.
----High Standard SMT&Solder Assembly Line
---- High density interconnected board placement technology capacity.
Quote requirement for pcb&pcb assembly:
----Gerber file and Bom list
----Clear pics of pcba or pcba sample for us
----Test method for PCBA
