Material
FR4,non-halogen material ,Aluminium Base,Cooper Base,high frequency material ,Thick copper foil,94-V0(HB),PI Material,HIGH TG:SL S1000-2,ITEQ:IT180
Surface Treatment
HAL,Immersion Gold,Immersion Tin,Immersion silver,Gold Finger,OSP,HAL(Immersion Gold,OSP,Immersion silver,Immersion Tin)+Gold Finger
Advantage
1.PCB factory directly
2.PCB high quality
3.PCB good price
4.PCB quick time
5.PCB certification(ISO/UL E354810/RoHS)
Capability:
-High Frequency (TACONIC material)/TG/Density/precision impedance controlled boards
-Heavy Copper PCB, Metal based PCB. Hard Gold PCB, Blind &Buried vias boards,
Halogen Free PCB, Aluminum-backed Boards
-Gold finger+ HAL & Leadfree HASL PCB, Leadfree compatible PCB
Product Details:
Payment & Shipping Terms:
|
| Base Material: | FR4 170 | Copper Thickness: | 1 Oz |
|---|---|---|---|
| Board Thickness: | 1.6mm | Min. Hole Size: | 0.2 Mm |
| Min. Line Width: | 4 Mil | Min. Line Spacing: | 5 Mil |
| Surface Finishing: | ENIG | Solder Mask: | Green |
| Silkscreen: | White | ||
| High Light: | high density board,custom circuit board |
||
Printed Circuit Board PCB manufacturer in Shenzhen
Material: FR-4
Copper: 1 oz
Thickness: 1.6mm
Solder mask: Green
Surface finish: ENIG + Gold finer
Quality: RoHS compliant
Quotation time:
1. For PCB & FPC: quotation within 1 hours if all information is clear.
2. For PCBA: quotation within 2 days if all information is clear.
One-stop Service:
1. PCB / FPC/ PCBA Copy
2. PCB drawing / design according to schematic diagram
3. PCB manufacturing
4. Component sourcing
5. PCB Assembly
6. PCBA test
Delivery Time:
| Layers | Sample | First Order | Repeat Order |
| Single side | 3 days | 7 days | 6 days |
| Double side | 4 days | 8 days | 7 days |
| 4 Layer | 7 days | 9 days | 8 days |
| 6 Layer | 8 days | 10 days | 9 days |
| 8 Layer | 10 days | 12 days | 10 days |
| 10 Layer | 12 days | 14 days | 12 days |
| Alu-base | 3 days | 8 days | 7 days |
| FPC 1 layer | 5 days | 8 days | 8 days |
Shipping Method:
1. By DHL, UPS, FedEx, TNT using clients account.
2. We suggest you using our DHL, UPS, FedEx, TNT forwarder.
3. By EMS (Usually for Russia Clients), price is high.
4. By sea for mass quantity according to customer's requirement.
5. By customer's Forwarder
Special Service / Fast PCB production / Short Leadtime
1. 2 layers within 24 hours
2. 4 layers within 48 hours
3. 6 layers within 72 hours
PCB Production Capability:
| Files | Gerber, Protel, Powerpcb, Autocad, Orcad, etc | |
| Material | FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic) | |
| Layer No. | 1 - 30 Layers | |
| Board thickness | 0.0075"(0.2mm)-0.125"(3.2mm) | |
| Board Thickness Tolerance | ±10% | |
| Copper thickness | 0.5OZ - 4OZ | |
| Impedance Control | ±10% | |
| Warpage | 0.075%-1.5% | |
| Peelable | 0.012"(0.3mm)-0.02’(0.5mm) | |
| Min Trace Width (a) | 0.005"(0.125mm) | |
| Min Space Width (b) | 0.005"(0.125mm) | |
| Min Annular Ring | 0.005"(0.125mm) | |
| SMD Pitch (a) | 0.012"(0.3mm) | |
| pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b) | 0.027"(0.675mm) | |
| Regesiter torlerance | 0.05mm | |
| Min Solder Mask Dam (a) | 0.005"(0.125mm) | |
| Soldermask Clearance (b) | 0.005"(0.125mm) | |
| Min SMT Pad spacing (c) | 0.004"(0.1mm) | |
| Solder Mask Thickness | 0.0007"(0.018mm) | |
| Hole size | 0.01"(0.25mm)-- 0.257"(6.5mm) | |
| Hole Size Tol (+/-) | ±0.003"(±0.0762mm) | |
| Aspect Ratio | 06:01 | |
| Hole Registration | 0.004"(0.1mm) | |
| HASL | 2.5um | |
| Lead free HASL | 2.5um | |
| Immersion Gold | Nickel 3-7um Au:1-3u'' | |
| OSP | 0.2-0.5um | |
| Panel Outline Tol (+/-) | ±0.004''(±0.1mm) | |
| Beveling | 30°45° | |
| V-cut | 15° 30° 45° 60° | |
| Surface finish | HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink, | |
| Certificate | ROHS ISO9001:2000 TS16949 SGS UL | |
| Special requirements | Buried and blind vias, Impedance control, via plug, BGA soldering and gold finger | |
